Video Input (IP): 2 channels (up to 18 channels), up to 5 MP resolution
Analog Video Input: 16 channels, BNC interface (75 Ω, 1.0 Vp-p), supports Coaxitron connection
Live View: 1080p
Video Recording: 720p
Video Formats
Type: HDTVI/AHD/CVI/CVBS/IP
VGA Output: 1 channel, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
HDMI Output: 1 channel, 1920 × 1080 /60 Hz, 1280 × 1024/ 60 Hz, 1280 × 720/ 60 Hz
Audio Input: 1 channel, RCA (2.0 Vp-p, 1 kΩ) and 16 channels via coaxial cable
Audio Output: 1 channel, RCA (Linear, 1 KΩ)
Recording
Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Frame Rate: Main stream: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF at 15 fps; sub-stream access: WD1/4CIF/VGA/CIF at 25 fps (P)/30 fps (N); 1080p and CIF/QVGA at 15 fps; SD stream access: CIF/QVGA at 25 fps (P)/30 fps (N)
Video Bitrate: 32 kbps to 4 Mbps
Stream Type: Video, Video & Audio
Audio Bit Rate: 64 Kbps
Network
Network Interface: 1 self-adaptive RJ45 10/100 Mbps Ethernet port
Total Bandwidth: 96 Mbps
Remote Connections: 128
Interface
HDD Type: SATA port
Storage Capacity: Up to 6 TB per HDD
USB: Rear panel: 2 × USB 2.0 ports
